Titan UVA LED
High-performance 365nm UV LED inspection lamp to produce bright fluorescent effects over a large area. With a rating of IP67, it is ideal for damp or wet environments, such as dye penetrant wash stations for NDT processes. Conforms with RRES 90061 and Airbus AITM6-1001.
- High UVA output at 365nm
- Produces bright fluorescent effects
- Contains 16 x UVA long-life LEDs
- Includes power supply and mounting bracket
- Conforms with RRES 90061 and Airbus AITM6-1001
Product Specification
The high-performance 365nm Titan UVA LED inspection lamp is engineered to produce bright fluorescent effects over a wide area, making it an excellent choice for various inspection applications. With a robust IP67 rating, this lamp is specifically designed to thrive in damp or wet environments, such as dye penetrant wash stations used in non-destructive testing (NDT) processes. Its durable construction ensures reliable operation even in challenging conditions, allowing professionals to perform inspections with confidence.
This versatile lamp is essential for enhancing visibility and ensuring thorough examinations in settings where moisture is a concern. Comprehensive health and safety information is included to guide users in the proper and safe use of the lamp, ensuring they can maximise its effectiveness while adhering to safety standards. Whether used in industrial, automotive, or aerospace applications, the Titan UVA LED is a vital tool for achieving high-quality inspection results.
Features & Specifications
- High UVA output at 365nm, the optimum wavelength for inspection applications
- Produces bright fluorescent effects over a large area
- IP67 – suitable for wet environments
- Includes mounting bracket
| Max. @ 38cm | 7,050 uW/cm2 |
| Max. @ 50cm | 4,390 uW/cm2 |
| Max. @ 100cm | 1,320 uW/cm2 |
| Max. @ 150cm | 830 uW/cm2 |
- Power supply
- Mounting bracket
- Operating manual
- Health and safety guidance
- 100-240 V (50-60 Hz)
| UV source | 16 x UVA LEDs |
| LED lifespan | 40,000 hours |
| UV peak output | 365nm ± 5nm |
| Wattage | 42W |
| Body material | Anodised aluminium |
| Weight | 1.5Kg |
| IP Rating | IP67 |
